Super Star DP MCB Circuit Breaker 20A - Reliable Electrical Protection for Your Home & Business
Ensure the utmost safety and reliability for your electrical systems with the Super Star DP MCB Circuit Breaker 20A. Designed to provide superior protection against overcurrent and short-circuit faults, this double-pole Miniature Circuit Breaker (MCB) is an essential component for any modern electrical installation in Bangladesh. With its robust construction, precise tripping mechanism, and adherence to international standards, the Super Star 20A DP MCB offers peace of mind, safeguarding your valuable appliances and, most importantly, lives.
Available at an unbeatable price of ৳599 BDT, this Super Star MCB is a smart investment for both residential and commercial applications across Bangladesh. Don't compromise on electrical safety – choose Super Star for proven performance and durability.
Overview: Super Star DP MCB 20A in Bangladesh
The Super Star DP MCB (Double Pole Miniature Circuit Breaker) 20A is engineered to protect two phases (Live and Neutral in a single-phase system, or two phases in a three-phase system) simultaneously. Rated at 20 amperes, it is ideal for circuits supplying medium-power loads such as air conditioners, water heaters, multiple light circuits, or power outlets in a specific zone. Super Star is a leading name in electrical accessories in the Bangladesh market, known for its commitment to quality and safety. This 20A MCB offers a C-type tripping characteristic, meaning it will trip when the current reaches 5 to 10 times its rated current, making it suitable for general-purpose circuits with moderate inrush currents.
Integrating this Super Star circuit breaker into your distribution board means you're choosing a product that meets stringent safety standards, ensuring quick and effective disconnection of power in fault conditions. Its compact design allows for easy installation on a standard DIN rail, making it a preferred choice for electricians and homeowners looking for reliable electrical protection in Bangladesh.
Key Features of Super Star DP MCB Circuit Breaker 20A
The Super Star DP MCB 20A comes packed with features designed for optimal performance and safety:
- Double Pole Protection: Simultaneously disconnects both the live and neutral conductors, providing complete isolation of the faulty circuit and enhanced safety.
- 20 Ampere Rating: Perfectly suited for a wide range of residential and commercial circuits that require a 20A current limit, protecting against overload and short circuits.
- High Breaking Capacity: Features a robust 6kA breaking capacity, capable of safely interrupting high fault currents without damage to the device.
- C-Type Tripping Characteristic: Ideal for general applications with inductive loads and moderate inrush currents, offering reliable protection for motors, transformers, and fluorescent lighting.
- Quick Trip Mechanism: Designed for rapid response to fault conditions, minimizing damage to appliances and preventing electrical hazards.
- DIN Rail Mountable: Standard 35mm DIN rail mounting ensures easy and secure installation in any standard distribution board or consumer unit.
- Durable Construction: Made from high-grade, fire-retardant thermoplastic materials, ensuring long-lasting performance and safety even under demanding conditions.
- Clear Indication Window: Features a clear ON/OFF indicator for easy status identification.
- Finger-Safe Terminals: Designed with safety in mind to prevent accidental contact with live parts during wiring.
- Compliance with IEC Standards: Manufactured in accordance with IEC 60898-1, guaranteeing international quality and safety benchmarks.
Technical Specifications
Understanding the technical specifications is crucial for proper selection and installation. Here are the detailed specifications for the Super Star DP MCB Circuit Breaker 20A:
Specifications Table
| Specification |
Value |
| Brand |
Super Star |
| Product Type |
Miniature Circuit Breaker (MCB) |
| Poles |
Double Pole (DP) |
| Rated Current (In) |
20A |
| Rated Voltage (Ue) |
230/400V AC |
| Rated Frequency |
50/60 Hz |
| Breaking Capacity (Icn) |
6kA |
| Tripping Characteristic |
C-Type |
| Electrical Life |
≥ 8,000 Cycles |
| Mechanical Life |
≥ 20,000 Cycles |
| Standard |
IEC 60898-1 |
| Terminal Capacity |
Up to 16mm² (flexible), Up to 25mm² (rigid) |
| Mounting Type |
35mm DIN Rail |
| Protection Degree |
IP20 (Terminals) |
| Operating Temperature |
-5°C to +40°C |
| Storage Temperature |
-25°C to +70°C |
| Dimensions (Approx.) |
82mm (Height) x 36mm (Width) x 70mm (Depth) |
| Weight (Approx.) |
180g |
| Material |
Fire-retardant Thermoplastic, Copper, Silver Alloy Contacts |
| Color |
White/Grey |
Benefits of Using Super Star DP MCB 20A
Investing in the Super Star DP MCB 20A brings numerous advantages to your electrical system:
- Enhanced Safety: Provides critical protection against overloads and short circuits, preventing electrical fires, equipment damage, and electric shocks.
- Reliable Performance: Super Star is a trusted brand in Bangladesh, known for producing durable and consistent electrical components that perform reliably over time.
- Cost-Effective Protection: At just ৳599 BDT, it offers premium safety features without breaking the bank, making it an accessible choice for all.
- Ease of Installation: Designed for quick and straightforward installation on standard DIN rails, reducing installation time and complexity.
- Long Service Life: High mechanical and electrical endurance ensures that the MCB will operate effectively for many years, minimizing replacement costs.
- Compliance and Trust: Adherence to IEC standards assures you of a product that meets rigorous international quality and safety benchmarks.
- Peace of Mind: Knowing your electrical circuits are protected by a high-quality Super Star MCB allows you to operate your appliances and systems with confidence.
Ideal Applications
The Super Star DP MCB Circuit Breaker 20A is versatile and suitable for a wide array of applications:
- Residential Buildings: Protecting individual circuits for heavy-duty appliances like air conditioners (up to 1.5-ton), water heaters, ovens, or main distribution for smaller apartments.
- Commercial Establishments: Ideal for office lighting circuits, dedicated power outlets for specific equipment, or small shop electrical panels.
- Small Workshops: Safeguarding power tool circuits or lighting setups in workshops.
- Garage and Outbuilding Circuits: Providing dedicated protection for electrical installations in garages, sheds, and other auxiliary structures.
- Distribution Boards: An essential component in new and upgraded distribution boards for comprehensive circuit protection.
Installation and Safety Guidelines
For optimal performance and safety, follow these guidelines when installing the Super Star DP MCB 20A:
- Professional Installation: Always have electrical devices installed by a qualified and certified electrician to ensure compliance with local wiring regulations and safety standards in Bangladesh.
- Power Disconnection: Before any installation or maintenance, ensure the main power supply to the distribution board is completely switched off and locked out.
- Correct Wiring: Connect the incoming live and neutral wires to the top terminals and the outgoing load wires to the bottom terminals as indicated on the MCB. Ensure tight and secure connections to prevent overheating.
- DIN Rail Mounting: Securely clip the MCB onto a standard 35mm DIN rail within the distribution board.
- Circuit Matching: Ensure the 20A rating of the MCB matches the current requirements and wire gauge of the circuit it is protecting. Using an undersized MCB will lead to nuisance tripping, while an oversized one may not provide adequate protection.
- Regular Inspection: Periodically check MCBs for any signs of damage, overheating, or loose connections.
Why Choose Super Star?
Super Star is a renowned brand in the electrical industry of Bangladesh, synonymous with quality, innovation, and customer satisfaction. When you choose a Super Star product, you're opting for:
- Proven Reliability: Years of experience and a strong market presence ensure that Super Star products are built to last and perform consistently.
- Commitment to Safety: All products, including the DP MCB 20A, undergo rigorous testing and adhere to international safety standards, providing unparalleled protection.
- Wide Availability: Super Star products are widely available across Bangladesh, making it easy to find and purchase genuine components.
- Excellent Value: Offering high-quality products at competitive prices, Super Star ensures you get the best value for your money.
Availability and Delivery in Bangladesh
You can easily purchase the Super Star DP MCB Circuit Breaker 20A from our online store or authorized dealers across Bangladesh. We offer nationwide delivery, ensuring that whether you are in Dhaka, Chittagong, Sylhet, Khulna, or any other part of the country, you can get this essential electrical safety device delivered right to your doorstep. For those searching for "Super Star DP MCB 20A near me," our extensive network of distributors and online platform makes it convenient to acquire this product quickly and efficiently. Experience hassle-free shopping and reliable delivery in Bangladesh.
Frequently Asked Questions (FAQs)
Q: What is the difference between a Single Pole and a Double Pole MCB?
A: A Single Pole MCB protects only the live wire, while a Double Pole (DP) MCB protects both the live and neutral wires simultaneously. A DP MCB offers enhanced safety by completely isolating the circuit during a fault.
Q: Can I use this 20A MCB for an air conditioner?
A: Yes, a 20A MCB is commonly used for 1.5-ton air conditioners, depending on their specific power draw. Always consult an electrician to verify the correct MCB rating for your appliance based on its power specifications.
Q: Is this Super Star MCB suitable for industrial use?
A: While it meets IEC standards, this 6kA breaking capacity MCB is primarily designed for residential and light commercial applications. For heavy industrial use, higher breaking capacity MCBs (e.g., 10kA or more) might be required, depending on the fault current levels in the industrial setup.
Q: What does "C-type tripping characteristic" mean?
A: C-type MCBs are designed to trip when the current reaches 5 to 10 times their rated current. This makes them suitable for general-purpose circuits with moderate inrush currents, such as those found in residential or light commercial settings with inductive loads like motors or fluorescent lights.
Invest in the Super Star DP MCB Circuit Breaker 20A today for unparalleled electrical safety and peace of mind. Get the best price in Bangladesh and reliable delivery for a product that truly protects.
