GearUP 8-Way DC PV Combiner Box with MCB, Fuse & SPD (IP65 Waterproof) – Advanced Solar System Protection in Bangladesh
Price: ৳8500.00 BDT
Power your solar journey with unparalleled safety and efficiency using the GearUP 8-Way DC PV Combiner Box. Engineered for robust performance and ultimate protection, this IP65 waterproof combiner box is an essential component for any serious solar photovoltaic (PV) installation in Bangladesh, ensuring your system operates reliably for years to come. Designed to consolidate up to eight individual solar PV strings, it provides comprehensive DC overcurrent, overvoltage, and surge protection, making it a critical investment for residential, commercial, and industrial solar projects.
Overview: The Heart of Your Solar Array's Safety
The GearUP 8-Way DC PV Combiner Box is more than just an enclosure; it's a sophisticated safety hub for your solar power system. In a multi-string PV array, individual strings generate varying current and voltage. This combiner box efficiently collects the output from up to eight strings, combining them into a single, manageable output to feed into your inverter. Beyond simple combination, its integrated protection features – including a high-capacity Main Circuit Breaker (MCB), individual string Fuses, and a Surge Protection Device (SPD) – safeguard your valuable solar panels and inverter from potential hazards like lightning strikes, short circuits, and overcurrent conditions. This robust design guarantees peace of mind, knowing your solar investment is protected against the unpredictable elements of nature and electrical faults.
For those searching for a reliable PV combiner box price in Bangladesh, the GearUP 8-Way offers exceptional value, combining premium features with a competitive price point. It's the ideal solution for optimizing your solar system's performance and longevity.
Why Choose the GearUP 8-Way DC PV Combiner Box?
- Enhanced Safety: Comprehensive protection against overcurrents, short circuits, and lightning surges.
- Improved System Reliability: Isolates faulty strings without affecting the entire array, minimizing downtime.
- Simplified Wiring: Reduces the number of cables running to the inverter, streamlining installation and maintenance.
- Weatherproof Durability: IP65 rating ensures protection against dust, water jets, and harsh outdoor conditions, perfect for the diverse climate in Bangladesh.
- Long-Term Investment: Protects expensive solar panels and inverters, extending the lifespan of your entire PV system.
Key Features
The GearUP 8-Way DC PV Combiner Box is packed with features designed for maximum performance and protection:
- 8-Way Input Configuration: Accommodates up to eight individual DC PV strings, suitable for medium to large-scale solar installations.
- Integrated DC Main Circuit Breaker (MCB): A powerful 125A, 1000V DC MCB provides primary overcurrent and short-circuit protection for the entire combined array, allowing for safe system disconnection.
- Individual String Fuses: Each of the eight input strings is protected by a dedicated 15A, 1000V DC fuse, isolating any faulty string to prevent cascading failures and simplify troubleshooting.
- High-Performance Surge Protection Device (SPD): A 1000V DC, 20-40kA SPD guards your system against dangerous voltage spikes caused by lightning or other transient events, diverting excess energy safely to the ground.
- IP65 Waterproof and Dustproof Enclosure: Constructed from high-quality, UV-resistant polycarbonate (PC), the robust enclosure ensures complete protection against dust ingress and powerful water jets, making it perfectly suited for outdoor installation in any weather condition prevalent in Bangladesh.
- MC4 Compatible Terminals: Features industry-standard MC4 input and output connectors for secure, reliable, and easy plug-and-play connections with your solar panels and inverter.
- Visual Fault Indicators: The SPD includes a visual status indicator (green for good, red for failed) for quick and easy health checks.
- Easy Installation: Designed for straightforward wall mounting with pre-drilled holes, making installation efficient for technicians.
- Safety Standards Compliant: Manufactured to meet rigorous international safety and quality standards (e.g., CE, RoHS equivalent for components), ensuring dependable operation.
- Corrosion Resistance: The high-grade enclosure material and internal components are selected for their resistance to corrosion, ensuring longevity in humid environments common in Bangladesh.
Technical Specifications
Understanding the technical details is crucial for integrating the GearUP 8-Way DC PV Combiner Box into your solar system. Here are the precise specifications:
Detailed Components
- DC Fuses: 8 sets of 15A/1000V DC fuses, specifically designed for PV applications.
- DC Main Circuit Breaker: 1 x 125A/1000V DC 2-pole MCB for main circuit protection and isolation.
- DC Surge Protection Device (SPD): 1 x 1000V DC, 20-40kA, Type 2 surge arrester with visual status indicator.
- Input Connectors: 8 pairs of MC4 compatible input terminals.
- Output Connectors: 1 pair of MC4 compatible output terminals.
- Grounding Terminal: Pre-installed grounding busbar for proper earthing.
| Specification |
Value |
| Model |
GearUP 8-Way DC PV Combiner Box |
| Number of Input Strings |
8 |
| Max Input Voltage (per string) |
1000V DC |
| Max Input Current (per string) |
15A |
| Total Output Voltage |
1000V DC |
| Total Output Current |
125A |
| Individual String Protection |
8 x 15A/1000V DC Fuses |
| Main Circuit Protection |
1 x 125A/1000V DC 2-Pole MCB |
| Surge Protection Device (SPD) |
1 x 1000V DC, 20-40kA, Type 2 |
| Enclosure Rating |
IP65 (Waterproof & Dustproof) |
| Enclosure Material |
UV-resistant Polycarbonate (PC) |
| Connectors |
MC4 Compatible Terminals |
| Operating Temperature Range |
-25°C to +60°C |
| Relative Humidity |
0-95% (non-condensing) |
| Installation Method |
Wall-mounted |
| Dimensions (L x W x H) |
400 mm x 320 mm x 160 mm |
| Weight |
6.5 kg |
| Color |
Grey/White (Standard Electrical Enclosure) |
| Certifications (Component Level) |
CE, RoHS compliant |
Benefits of Using a PV Combiner Box
A PV combiner box is an indispensable part of a well-designed solar power system. Its benefits extend far beyond simple wire management:
- Maximized Power Harvest: By combining strings efficiently, it ensures that your inverter receives a stable and optimized DC input, contributing to higher overall energy generation.
- Simplified Troubleshooting: Individual string fusing allows for quick identification and isolation of faulty strings. If one string fails, only that string's fuse blows, keeping the rest of the array operational and making repairs much faster.
- Enhanced Electrical Safety: The MCB acts as a master disconnect switch, allowing for safe shutdown and maintenance of the DC side of your system. The SPD protects against dangerous voltage surges that could otherwise fry your inverter or panels.
- Reduced Wiring Complexity: Instead of running multiple cables from each string to the inverter, the combiner box consolidates them into one main DC output cable, reducing material costs, installation time, and potential points of failure.
- Compliance with Safety Standards: Many electrical codes and standards require overcurrent and surge protection for PV systems, which a well-equipped combiner box like the GearUP 8-Way readily provides.
- Increased System Longevity: By protecting critical components from electrical stresses and environmental factors, the combiner box significantly extends the operational life of your entire solar PV installation.
Ideal Applications
The GearUP 8-Way DC PV Combiner Box is perfectly suited for a wide range of solar applications:
- Large Residential Solar Systems: For homes with extensive rooftop arrays requiring multiple strings.
- Commercial & Industrial Rooftop Installations: Essential for businesses looking to reduce electricity costs with solar power.
- Ground-Mounted Solar Farms: Provides robust protection for larger, utility-scale projects.
- Off-Grid and Hybrid Systems: Ensures reliable power delivery and protection for remote installations.
- Solar Water Pumping Systems: Protects the DC side of pumps from surges and overcurrents.
Installation and Safety Guidelines
While the GearUP 8-Way DC PV Combiner Box is designed for easy installation, professional installation by a certified solar technician is highly recommended to ensure safety and compliance with local electrical codes in Bangladesh. Always follow these general guidelines:
- Mounting: Securely mount the combiner box in a shaded, easily accessible location, preferably near the solar array and inverter. Use appropriate mounting hardware for the wall material.
- Wiring: Ensure all DC wiring is correctly polarized (+ to + and – to –). Use proper tools for crimping MC4 connectors to ensure secure and low-resistance connections.
- Grounding: Connect the combiner box to a reliable earth ground using the designated grounding terminal. This is crucial for the SPD to function effectively during a surge event.
- Testing: Before energizing the system, perform voltage and continuity checks on all strings and the combined output to verify correct wiring.
- Safety First: Always wear appropriate personal protective equipment (PPE), including insulated gloves and safety glasses, when working with live DC electrical systems. Disconnect all power sources before performing any maintenance.
Availability and Price in Bangladesh
The GearUP 8-Way DC PV Combiner Box with MCB, Fuse & SPD (IP65 Waterproof) is readily available in Bangladesh. You can purchase this essential solar component for ৳8500.00 BDT. We strive to offer the best price in Bangladesh for high-quality solar protection equipment.
You can find this product at leading solar equipment suppliers, authorized GearUP dealers, and reputable online e-commerce platforms across the country. For those searching for "GearUP 8-Way DC PV Combiner Box near me," please check our dealer network or contact us directly for delivery options throughout Bangladesh. We ensure prompt and secure delivery in Bangladesh, bringing top-tier solar solutions right to your doorstep.
Customer Satisfaction and Warranty
GearUP is committed to providing high-quality, reliable solar components. The 8-Way DC PV Combiner Box undergoes stringent quality control to ensure it meets the demands of the Bangladesh market and beyond. We offer a standard warranty against manufacturing defects, underscoring our confidence in the product's durability and performance. Our customer support team is always ready to assist with any queries or technical support you may require.
Conclusion
Investing in the GearUP 8-Way DC PV Combiner Box with MCB, Fuse & SPD (IP65 Waterproof) is a smart decision for anyone serious about the longevity and safety of their solar photovoltaic system. With its robust construction, comprehensive protection features, and competitive price in Bangladesh (৳8500.00 BDT), it stands out as a superior choice. Ensure your solar array is protected against all odds and operates at peak efficiency for years to come with GearUP.
